MiG-27

Belle étude d'un MiG-27 - sans suffixe - "Flogger-D" du 19.GvAPIB armé d'un conteneur lance-roquettes UB-16-57UMVP. Un lance-bombes en tandem MBD3-2UT-1 est attaché sous la partie fixe de l'aile. On distingue juste au-dessus de ce dernier le carénage pointu de l'antenne de guidage du système Del'ta permettant le tir de missiles radio-guidés Kh-23 et Kh-25.

Nice study of a MiG-27 - without suffix - "Flogger-D" of the 19.GvAPIB armed with an UB-16-57UMVP rocket launcher. A MBD3-2UT-1 tandem ejector rack is attached under the fixed part of the wing. We can see just above the latter the pointed fairing of the guidance antenna from the Del'ta system allowing the firing of radio-guided Kh-23 and Kh-25 missiles.
